6장. 파일 업로드 처리

ch21. 파일 업로드 방식

  • 파일 업로드 방식
    • <form> 태그를 이용하는 방식
      • 브라우저의 제한이 없어야 하는 경우에 사용
      • 일반적으로 페이지 이동과 동시에 첨부파일을 업로드하는 방식
      • <iframe>을 이용해서 화면의 이동 없이 첨부파일을 처리하는 방식
    • Ajax를 이용한 방식
      • 첨부파일을 별도로 처리하는 방식
      • <input type="file">을 이용하고 Ajax로 처리하는 방식
      • HTML5의 Drag And Drop 기능이나 jQuery 라이브러리를 이용해서 처리하는 방식

  • <form> 방식의 파일 업로드

    uploadForm.jsp

      <%@ page language="java" contentType="text/html; charset=UTF-8"
  pageEncoding="UTF-8"%>
  <!DOCTYPE html>
  <html>
  <head>
  <meta charset="UTF-8">
  <title>Insert title here</title>
  </head>
  <body>
      <from action="uploadFormAction" method="post" enctype="mulipart/form-data">
      <input type="file" name="uploadFile" multiple>
      <button>Submit</button>
      </from>
  </body>
  </html>

    UploadController.java

      package org.zerock.controller;

  import java.io.File;

  import org.springframework.stereotype.Controller;
  import org.springframework.ui.Model;
  import org.springframework.web.bind.annotation.GetMapping;
  import org.springframework.web.bind.annotation.PostMapping;
  import org.springframework.web.multipart.MultipartFile;

  import lombok.extern.log4j.Log4j;

  @Controller
  @Log4j
  public class UploadController {
      @GetMapping("/uploadForm")
      public void uploadForm() {

          log.info("upload form");
      }

      @PostMapping("/uploadFormAction")
      public void uploadFormPost(MultipartFile[] uploadFile, Model model) {

          String uploadFolder = "/Users/tongbook/Desktop/study/upload";

          for(MultipartFile multipartFile : uploadFile) {
              log.info("----------------------");
              log.info("Upload File Name: " + multipartFile.getOriginalFilename());
              log.info("Upload File Size: " + multipartFile.getSize());

              File saveFile = new File(uploadFolder, multipartFile.getOriginalFilename());

              try {
                  multipartFile.transferTo(saveFile);
              }catch(Exception e) {
                  log.error(e.getMessage());
              }
          }
      }
  }

  • Ajax를 이용하는 파일 업로드

    • Ajax는 FormData 타입의 객체에 파일을 담음 (가상의 form태그 와 같다고 생각하면 쉬움)

      uploadAjax.jsp

      <%@ page language="java" contentType="text/html; charset=UTF-8"
pageEncoding="UTF-8"%>
<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8">
<title>Insert title here</title>
</head>
<body>
  <h1>Upload with Ajax</h1>

  <div class="uploadDiv">
      <input type="file" name="uploadFile" multiple>
  </div>

  <button id="uploadBtn">Upload</button>

  <script src="https://code.jquery.com/jquery-3.5.0.js"
  integrity="sha256-r/AaFHrszJtwpe+tHyNi/XCfMxYpbsRg2Uqn0x3s2zc="
  crossorigin="anonymous"></script>

  <script>
      $(document).ready(function(){
          $("#uploadBtn").on("click", function(e){
              var formData = new FormData();

              var inputFile = $("input[name='uploadFile']");

              var files = inputFile[0].files;

              console.log(files);

              //add filedata to formData
              for(var i=0; i<files.length; i++){
                  formData.append("uploadFile", files[i]);
              }

              $.ajax({
                  url : "/uploadAjaxAction",
                  processData : false,    // ajax로 파일 전송 시 반드시 false
                  contentType : false,    // ajax로 파일 전송 시 반드시 false
                  data : formData,
                  type : "POST",
                  success : function(result){
                      alert("uploaded");
                  }
              });
          });
      });
  </script>
</body>
</html>

      uploadController.java

      @GetMapping("/uploadAjax")
public void uploadAjax() {
  log.info("upload ajax");
}

@PostMapping("/uploadAjaxAction")
public void uploadAjaxPost(MultipartFile[] uploadFile) {
  log.info("update ajax post");

  String uploadFolder = "/Users/tongbook/Desktop/study/upload";

  for(MultipartFile multipartFile : uploadFile) {
      log.info("----------------");
      log.info("Upload File Name : " + multipartFile.getOriginalFilename());
      log.info("Upload File Size : " + multipartFile.getSize());

      String uploadFileName = multipartFile.getOriginalFilename();

      // IE has file path
      uploadFileName = uploadFileName.substring(uploadFileName.lastIndexOf("\\") + 1);
      log.info("only file name : " + uploadFileName);

      File saveFile = new File(uploadFolder, uploadFileName);

      try {
          multipartFile.transferTo(saveFile);
      }catch(Exception e) {
          log.error(e.getMessage());
      }
  }
}

ch22. 파일 업로드 상세 처리

  • 고려해야 하는점

    • 동일한 이름으로 파일이 업로드 되었을 때 기존 파일이 사라지는 문제
    • 이미지 파일의 경우에는 원본 파일의 용량이 큰 경우 섬네일 이미지를 생성해야 하는 문제
    • 이미지 파일과 일반 파일을 구분해서 다운로드 혹은 페이지에서 조회하도록 처리하는 문제
    • 첨부파일 공격에 대비하기 위한 업로드 파일의 확장자 제한

  • 파일의 확장자나 크기의 사전 처리

    uploadAjax.jsp

      <script>
      var regex = new RegExp("(.*?)\.(exe|sh|zip|alz)$");
      var maxSize = 5242880;    // 5MB

      function checkExtension(fileName, fileSize){
          if(fileSize >= maxSize){
              alert("파일 사이즈 초과");
              return false;
          }

          if(regex.test(fileName)){
              alert("당 종류의 파일은 업로드할 수 없습니다.");
              return false;
          }
          return true;
      }

      $(document).ready(function(){
          $("#uploadBtn").on("click", function(e){
              var formData = new FormData();

              var inputFile = $("input[name='uploadFile']");

              var files = inputFile[0].files;

              console.log(files);

              //add filedata to formData
              for(var i=0; i<files.length; i++){

                  if(!checkExtension(files[i].name, files[i].size)){
                      return false;
                  }

                  formData.append("uploadFile", files[i]);
              }

              $.ajax({
                  url : "/uploadAjaxAction",
                  processData : false,    // ajax로 파일 전송 시 반드시 false
                  contentType : false,    // ajax로 파일 전송 시 반드시 false
                  data : formData,
                  type : "POST",
                  success : function(result){
                      alert("uploaded");
                  }
              });
          });
      });
  </script>

  • 중복 방지를 위한 UUID 적용

    • UploadController

      @PostMapping("/uploadAjaxAction")
public void uploadAjaxPost(MultipartFile[] uploadFile) {
  log.info("update ajax post");

  String uploadFolder = "/Users/tongbook/Desktop/study/upload";

  // 폴더 생성
  File uploadPath = new File(uploadFolder, getFolder());
  log.info("upload path : " + uploadPath);

  if(uploadPath.exists() == false) {
      uploadPath.mkdir();    // yyyy/mm/dd
  }
  // 생성 종료

  for(MultipartFile multipartFile : uploadFile) {
      log.info("----------------");
      log.info("Upload File Name : " + multipartFile.getOriginalFilename());
      log.info("Upload File Size : " + multipartFile.getSize());

      String uploadFileName = multipartFile.getOriginalFilename();

      // IE has file path
      uploadFileName = uploadFileName.substring(uploadFileName.lastIndexOf("\\") + 1);
      log.info("only file name : " + uploadFileName);

      UUID uuid = UUID.randomUUID();

      uploadFileName = uuid.toString() + "_" + uploadFileName;

      File saveFile = new File(uploadPath, uploadFileName);

      try {
          multipartFile.transferTo(saveFile);
      }catch(Exception e) {
          log.error(e.getMessage());
      }
  }
}

  • 섬네일 이미지 생성

    • pom.xml

      <!-- https://mvnrepository.com/artifact/net.coobird/thumbnailator -->
<dependency>
  <groupId>net.coobird</groupId>
  <artifactId>thumbnailator</artifactId>
  <version>0.4.11</version>
</dependency>

    • UploadController.java

      private boolean checkImageType(File file) {
  try {
      // Mac OS 에서 확장자를 못찾아서 null 값이 들어
      //String contentType = Files.probeContentType(file.toPath());
      //log.info("contentType : " + contentType);
      //return contentType.startsWith("image");

      // MacOS에서도 동작하지만 파일의 크기가 커지면 속도가 느려지는 문제점이 있음
      MimetypesFileTypeMap mimetypesFileTypeMap = new MimetypesFileTypeMap();

      String contentType = mimetypesFileTypeMap.getContentType(file);

      if(contentType.contains("image")) {
          return true;
      }
  }catch(Exception e) {
      e.getMessage();
  }

  return false;
}
      @PostMapping("/uploadAjaxAction")
public void uploadAjaxPost(MultipartFile[] uploadFile) {
  log.info("update ajax post");

  String uploadFolder = "/Users/tongbook/Desktop/study/upload";

  // 폴더 생성
  File uploadPath = new File(uploadFolder, getFolder());
  log.info("upload path : " + uploadPath);

  if(uploadPath.exists() == false) {
      uploadPath.mkdir();    // yyyy/mm/dd
  }
  // 생성 종료

  for(MultipartFile multipartFile : uploadFile) {
      log.info("----------------");
      log.info("Upload File Name : " + multipartFile.getOriginalFilename());
      log.info("Upload File Size : " + multipartFile.getSize());

      String uploadFileName = multipartFile.getOriginalFilename();

      // IE has file path
      uploadFileName = uploadFileName.substring(uploadFileName.lastIndexOf("\\") + 1);
      log.info("only file name : " + uploadFileName);

      UUID uuid = UUID.randomUUID();

      uploadFileName = uuid.toString() + "_" + uploadFileName;

      try {
          File saveFile = new File(uploadPath, uploadFileName);
          multipartFile.transferTo(saveFile);

          if(checkImageType(saveFile)) {
              FileOutputStream thumbnail = new FileOutputStream(new File(uploadPath, "s_" + uploadFileName));

              Thumbnailator.createThumbnail(multipartFile.getInputStream(), thumbnail, 100, 100);

              thumbnail.close();
          }
      }catch(Exception e) {
          log.error(e.getMessage());
      }
  }
}

  • 업로드된 파일의 데이터 반환

    • 브라우저로 전송할 데이터 정보

      • 업로드된 파일의 이름과 원본 파일의 이름
      • 파일이 저장된 경로
      • 업로드된 파일이 이미지인지 아닌지에 대한 정보

    • pom.xml

      <!-- https://mvnrepository.com/artifact/com.fasterxml.jackson.core/jackson-databind -->
<dependency>
  <groupId>com.fasterxml.jackson.core</groupId>
  <artifactId>jackson-databind</artifactId>
  <version>2.9.5</version>
</dependency>

<dependency>
  <groupId>com.fasterxml.jackson.dataformat</groupId>
  <artifactId>jackson-dataformat-xml</artifactId>
  <version>2.9.5</version>
</dependency>

    • AttachFileDTO.java

      package org.zerock.domain;

import lombok.Data;

@Data
public class AttachFileDTO {
  private String fileName;
  private String uploadPath;
  private String uuid;
  private boolean image;
}

    • UploadController.java

      @PostMapping(value = "/uploadAjaxAction", produces=MediaType.APPLICATION_JSON_UTF8_VALUE)
@ResponseBody
public ResponseEntity<List<AttachFileDTO>> uploadAjaxPost(MultipartFile[] uploadFile) {
  log.info("update ajax post");

  List<AttachFileDTO> list = new ArrayList();

  String uploadFolder = "/Users/tongbook/Desktop/study/upload";

  String uploadFolderPath = getFolder();

  // 폴더 생성
  File uploadPath = new File(uploadFolder, uploadFolderPath);
  log.info("upload path : " + uploadPath);

  if(uploadPath.exists() == false) {
      uploadPath.mkdir();    // yyyy/mm/dd
  }
  // 생성 종료

  for(MultipartFile multipartFile : uploadFile) {
      log.info("----------------");
      log.info("Upload File Name : " + multipartFile.getOriginalFilename());
      log.info("Upload File Size : " + multipartFile.getSize());

      AttachFileDTO attachDTO = new AttachFileDTO();

      String uploadFileName = multipartFile.getOriginalFilename();

      // IE has file path
      uploadFileName = uploadFileName.substring(uploadFileName.lastIndexOf("\\") + 1);
      log.info("only file name : " + uploadFileName);
      attachDTO.setFileName(uploadFileName);

      UUID uuid = UUID.randomUUID();

      uploadFileName = uuid.toString() + "_" + uploadFileName;

      try {
          File saveFile = new File(uploadPath, uploadFileName);
          multipartFile.transferTo(saveFile);

          attachDTO.setUuid(uuid.toString());
          attachDTO.setUploadPath(uploadFolderPath);

          if(checkImageType(saveFile)) {

              attachDTO.setImage(true);

              FileOutputStream thumbnail = new FileOutputStream(new File(uploadPath, "s_" + uploadFileName));

              Thumbnailator.createThumbnail(multipartFile.getInputStream(), thumbnail, 100, 100);

              thumbnail.close();
          }

          list.add(attachDTO);
      }catch(Exception e) {
          log.error(e.getMessage());
      }
  }

  return new ResponseEntity<>(list, HttpStatus.OK);
}

    • uploadAjax.jsp

      $.ajax({
  url : "/uploadAjaxAction",
  processData : false,    // ajax로 파일 전송 시 반드시 false
  contentType : false,    // ajax로 파일 전송 시 반드시 false
  data : formData,
  type : "POST",
  dataType : "json",
  success : function(result){
      console.log(result);
  }
});

  • 파일 업로드 후 초기화

    • uploadAjax.jsp

      $(document).ready(function(){

  var cloneObj = $(".uploadDiv").clone();

  $("#uploadBtn").on("click", function(e){
      var formData = new FormData();

      var inputFile = $("input[name='uploadFile']");

      var files = inputFile[0].files;

      console.log(files);

      //add filedata to formData
      for(var i=0; i<files.length; i++){

          if(!checkExtension(files[i].name, files[i].size)){
              return false;
          }

          formData.append("uploadFile", files[i]);
      }

      $.ajax({
          url : "/uploadAjaxAction",
          processData : false,    // ajax로 파일 전송 시 반드시 false
          contentType : false,    // ajax로 파일 전송 시 반드시 false
          data : formData,
          type : "POST",
          dataType : "json",
          success : function(result){
              console.log(result);

              $(".uploadDiv").html(cloneObj.html());
          }
      });
  });
});

  • 썸네일 이미지 보여주기 (최종 소스)

    • UploadController.java

      package org.zerock.controller;

import org.zerock.domain.AttachFileDTO;

import java.io.File;
import java.io.FileOutputStream;
import java.io.IOException;
import java.nio.file.Files;
import java.text.SimpleDateFormat;
import java.util.ArrayList;
import java.util.Date;
import java.util.List;
import java.util.UUID;

import javax.activation.MimetypesFileTypeMap;

import org.springframework.http.HttpHeaders;
import org.springframework.http.HttpStatus;
import org.springframework.http.MediaType;
import org.springframework.http.ResponseEntity;
import org.springframework.stereotype.Controller;
import org.springframework.ui.Model;
import org.springframework.util.FileCopyUtils;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PostMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.multipart.MultipartFile;

import lombok.extern.log4j.Log4j;
import net.coobird.thumbnailator.Thumbnailator;

@Controller
@Log4j
public class UploadController {
  @GetMapping("/uploadForm")
  public void uploadForm() {

      log.info("upload form");
  }

  @PostMapping("/uploadFormAction")
  public void uploadFormPost(MultipartFile[] uploadFile, Model model) {

      String uploadFolder = "/Users/tongbook/Desktop/study/upload";

      for(MultipartFile multipartFile : uploadFile) {
          log.info("----------------------");
          log.info("Upload File Name: " + multipartFile.getOriginalFilename());
          log.info("Upload File Size: " + multipartFile.getSize());

          File saveFile = new File(uploadFolder, multipartFile.getOriginalFilename());

          try {
              multipartFile.transferTo(saveFile);
          }catch(Exception e) {
              log.error(e.getMessage());
          }
      }
  }

  @GetMapping("/uploadAjax")
  public void uploadAjax() {
      log.info("upload ajax");
  }

  @PostMapping(value = "/uploadAjaxAction", produces=MediaType.APPLICATION_JSON_UTF8_VALUE)
  @ResponseBody
  public ResponseEntity<List<AttachFileDTO>> uploadAjaxPost(MultipartFile[] uploadFile) {
      log.info("update ajax post");

      List<AttachFileDTO> list = new ArrayList();

      String uploadFolder = "/Users/tongbook/Desktop/study/upload";

      String uploadFolderPath = getFolder();

      // 폴더 생성
      File uploadPath = new File(uploadFolder, uploadFolderPath);
      log.info("upload path : " + uploadPath);

      if(uploadPath.exists() == false) {
          uploadPath.mkdir();    // yyyy/mm/dd
      }
      // 생성 종료

      for(MultipartFile multipartFile : uploadFile) {
          log.info("----------------");
          log.info("Upload File Name : " + multipartFile.getOriginalFilename());
          log.info("Upload File Size : " + multipartFile.getSize());

          AttachFileDTO attachDTO = new AttachFileDTO();

          String uploadFileName = multipartFile.getOriginalFilename();

          // IE has file path
          uploadFileName = uploadFileName.substring(uploadFileName.lastIndexOf("\\") + 1);
          log.info("only file name : " + uploadFileName);
          attachDTO.setFileName(uploadFileName);

          UUID uuid = UUID.randomUUID();

          uploadFileName = uuid.toString() + "_" + uploadFileName;

          try {
              File saveFile = new File(uploadPath, uploadFileName);
              multipartFile.transferTo(saveFile);

              attachDTO.setUuid(uuid.toString());
              attachDTO.setUploadPath(uploadFolderPath);

              if(checkImageType(saveFile)) {

                  attachDTO.setImage(true);

                  FileOutputStream thumbnail = new FileOutputStream(new File(uploadPath, "s_" + uploadFileName));

                  Thumbnailator.createThumbnail(multipartFile.getInputStream(), thumbnail, 100, 100);

                  thumbnail.close();
              }

              list.add(attachDTO);
          }catch(Exception e) {
              log.error(e.getMessage());
          }
      }

      return new ResponseEntity<>(list, HttpStatus.OK);
  }

  private String getFolder() {
      SimpleDateFormat sdf = new SimpleDateFormat("yyyy-MM-dd");

      Date date = new Date();

      String str = sdf.format(date);

      return str.replace("-", File.pathSeparator);
  }

  private boolean checkImageType(File file) {
      try {
          // Mac OS 에서 확장자를 못찾아서 null 값이 들어
          //String contentType = Files.probeContentType(file.toPath());
          //log.info("contentType : " + contentType);
          //return contentType.startsWith("image");

          MimetypesFileTypeMap mimetypesFileTypeMap = new MimetypesFileTypeMap();

          String contentType = mimetypesFileTypeMap.getContentType(file);

          if(contentType.contains("image")) {
              return true;
          }
      }catch(Exception e) {
          e.getMessage();
      }

      return false;
  }

  @GetMapping("/display")
  @ResponseBody
  public ResponseEntity<byte[]> getFile(String fileName){
      log.info("fileName : " + fileName);

      File file = new File("/Users/tongbook/Desktop/study/upload/" + fileName);

      log.info("file: " + file);

      ResponseEntity<byte[]> result = null;

      try {
          HttpHeaders header = new HttpHeaders();

          header.add("Content-Type", Files.probeContentType(file.toPath()));
          result = new ResponseEntity<>(FileCopyUtils.copyToByteArray(file), header, HttpStatus.OK);
      }catch(IOException e) {
          e.printStackTrace();
      }

      return result;
  }
}

    • uploadAjax.jsp

      <%@ page language="java" contentType="text/html; charset=UTF-8"
pageEncoding="UTF-8"%>
<!DOCTYPE html>
<html>
<head>
<meta charset="UTF-8">
<title>Insert title here</title>
</head>
<body>
  <h1>Upload with Ajax</h1>

  <div class="uploadDiv">
      <input type="file" name="uploadFile" multiple>
  </div>

  <style type="text/css">
      .uploadResult{
          width:100%;
          background-color: gray;
      }

      .uploadResult ul{
          display:flex;
          flex-flow: row;
          justify-content: center;
          align-items: center;
      }

      .uploadResult ul li {
          list-style: none;
          padding: 10px;
      }

      .uploadResult ul li img{
          width: 100px;
      }
  </style>
  <div class="uploadResult">
      <ul>
      </ul>
  </div>

  <button id="uploadBtn">Upload</button>

  <script src="https://code.jquery.com/jquery-3.5.0.js"
  integrity="sha256-r/AaFHrszJtwpe+tHyNi/XCfMxYpbsRg2Uqn0x3s2zc="
  crossorigin="anonymous"></script>

  <script>
      var regex = new RegExp("(.*?)\.(exe|sh|zip|alz)$");
      var maxSize = 5242880;    // 5MB

      function checkExtension(fileName, fileSize){
          if(fileSize >= maxSize){
              alert("파일 사이즈 초과");
              return false;
          }

          if(regex.test(fileName)){
              alert("당 종류의 파일은 업로드할 수 없습니다.");
              return false;
          }
          return true;
      }

      var uploadResult = $(".uploadResult ul");

      function showUploadedFile(uploadResultArr){
          var str = "";

          $(uploadResultArr).each(function(i,obj){
              if(!obj.image){
                  str += "<li><img src='/resources/img/attach.png'>" + obj.fileName + "</li>";
              }else{
                  //str += "<li>" + obj.fileName + "</li>";

                  var fileCallPath = encodeURIComponent(obj.uploadPath+"/s_" + obj.uuid + "_" + obj.fileName);

                  str += "<li><img src='/display?fileName=" + fileCallPath + "'></li>";
              }
          });

          uploadResult.append(str);
      }

      $(document).ready(function(){

          var cloneObj = $(".uploadDiv").clone();

          $("#uploadBtn").on("click", function(e){
              var formData = new FormData();

              var inputFile = $("input[name='uploadFile']");

              var files = inputFile[0].files;

              console.log(files);

              //add filedata to formData
              for(var i=0; i<files.length; i++){

                  if(!checkExtension(files[i].name, files[i].size)){
                      return false;
                  }

                  formData.append("uploadFile", files[i]);
              }

              $.ajax({
                  url : "/uploadAjaxAction",
                  processData : false,    // ajax로 파일 전송 시 반드시 false
                  contentType : false,    // ajax로 파일 전송 시 반드시 false
                  data : formData,
                  type : "POST",
                  dataType : "json",
                  success : function(result){
                      console.log(result);

                      showUploadedFile(result);

                      $(".uploadDiv").html(cloneObj.html());
                  }
              });
          });
      });
  </script>
</body>
</html>

ch24. 첨부파일의 다운로드

  • 간단한 첨부파일의 다운로드 처리
    • MIME 타입을 다운로드 타입으로 지정

  • 첨부파일 다운로드

    • UplaodController.java

      @GetMapping(value="/download", produces=MediaType.APPLICATION_OCTET_STREAM_VALUE)
@ResponseBody
public ResponseEntity<Resource> downloadFile(@RequestHeader("User-Agent") String userAgent, String fileName){
  log.info("download file : " + fileName);

  Resource resource = new FileSystemResource("/Users/tongbook/Desktop/study/upload/" + fileName);

  if(resource.exists() == false) {
      return new ResponseEntity<>(HttpStatus.NOT_FOUND);
  }

  log.info("resource : " + resource);

  String resourceName = resource.getFilename();

  String resourceOriginalName = resourceName.substring(resourceName.indexOf("_") + 1);

  HttpHeaders headers = new HttpHeaders();

  try {
      String downloadName = null;

      if(userAgent.contains("Trident")) {
          log.info("IE browser");

          downloadName = URLEncoder.encode(resourceOriginalName, "UTF-8").replaceAll("\\+", " ");
      }else if(userAgent.contains("Edge")) {
          log.info("Edge browser");

          downloadName = URLEncoder.encode(resourceOriginalName, "UTF-8");
      }else {
          log.info("Chrome browser");

          downloadName = new String(resourceOriginalName.getBytes("UTF-8"), "ISO-8859-1");
      }

      log.info("downloadName : " + downloadName);
      headers.add("Content-Disposition", "attachment; filename=" + downloadName);
  }catch(UnsupportedEncodingException e) {
      e.printStackTrace();
  }

  return new ResponseEntity<Resource>(resource, headers, HttpStatus.OK);
}

    • uploadAjax.jsp

      function showUploadedFile(uploadResultArr){
  var str = "";

  $(uploadResultArr).each(function(i,obj){
      if(!obj.image){
          var fileCallPath = encodeURIComponent(obj.uploadPath + "/" + obj.uuid + "_" + obj.fileName);

          str += "<li><a href='/download?fileName=" + fileCallPath + "'><img src='/resources/img/attach.png'>" + obj.fileName + "</a></li>";
      }else{
          //str += "<li>" + obj.fileName + "</li>";

          var fileCallPath = encodeURIComponent(obj.uploadPath+"/s_" + obj.uuid + "_" + obj.fileName);

          str += "<li><img src='/display?fileName=" + fileCallPath + "'></li>";
      }
  });

  uploadResult.append(str);
}

  • 첨부파일 삭제

    • uploadAjax.jsp

      function showUploadedFile(uploadResultArr){
  var str = "";

  $(uploadResultArr).each(function(i,obj){
      if(!obj.image){
          var fileCallPath = encodeURIComponent(obj.uploadPath + "/" + obj.uuid + "_" + obj.fileName);

          str += "<li><a href='/download?fileName=" + fileCallPath + "'><img src='/resources/img/attach.png'>" + obj.fileName + "</a>" +
          "<span data-file=\'" + fileCallPath + "\' data-type='file'> x </span></li>";
      }else{
          //str += "<li>" + obj.fileName + "</li>";

          var fileCallPath = encodeURIComponent(obj.uploadPath+"/s_" + obj.uuid + "_" + obj.fileName);

          str += "<li><img src='/display?fileName=" + fileCallPath + "'><span data-file=\'" + fileCallPath + "\' data-type='file'> x </span></li>";
      }
  });

  uploadResult.append(str);
}
      $(".uploadResult").on("click", "span", function(e){
  var targetFile = $(this).data("file");
  var type = $(this).data("type");
  console.log(targetFile);

  $.ajax({
      url : "/deleteFile",
      data : {fileName : targetFile, type : type},
      dataType : "text",
      type : "POST",
      success : function(result){
          alert(result);
      }
  });
});

    • UploadController.java

      @PostMapping("/deleteFile")
@ResponseBody
public ResponseEntity<String> deleteFile(String fileName, String type){
  log.info("deleteFile : " + fileName);
  log.info("type : " + type);

  File file;

  try {
      file = new File("/Users/tongbook/Desktop/study/upload/" + URLDecoder.decode(fileName, "UTF-8"));

      file.delete();

      if(type.equals("image")) {
          String largeFileName = file.getAbsolutePath().replace("s_", "");

          log.info("largeFileName : " + largeFileName);

          file = new File(largeFileName);

          file.delete();
      }
  }catch(UnsupportedEncodingException e) {
      e.printStackTrace();

      return new ResponseEntity<>(HttpStatus.NOT_FOUND);
  }

  return new ResponseEntity<String>("deleted", HttpStatus.OK);
}

프로젝트 실제 반영 소스

  • AttachFileDTO.java
package org.zerock.mapper;

import java.util.List;

import org.zerock.domain.BoardAttachVO;

public interface BoardAttachMapper {
    public void insert(BoardAttachVO vo);

    public void delete(String uuid);

    public List<BoardAttachVO> findByBno(Long bno);

    public void deleteAll(Long bno);
}
  • BoardVO.java
package org.zerock.domain;

import java.util.Date;
import java.util.List;

import lombok.Data;

@Data
public class BoardVO {
    private Long bno;
    private String title;
    private String content;
    private String writer;
    private Date regdate;
    private Date updateDate;

    private int replyCnt;

    private List<BoardAttachVO> attachList;
}
  • BoardAttachMapper.java
package org.zerock.mapper;

import java.util.List;

import org.zerock.domain.BoardAttachVO;

public interface BoardAttachMapper {
    public void insert(BoardAttachVO vo);

    public void delete(String uuid);

    public List<BoardAttachVO> findByBno(Long bno);

    public void deleteAll(Long bno);
}
  • BoardAttachMapper.xml
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE mapper PUBLIC "-//mybatis.org/DTD Mapper 3.0//EN" "http://mybatis.org/dtd/mybatis-3-mapper.dtd">

<mapper namespace="org.zerock.mapper.BoardAttachMapper">
    <insert id="insert">
        insert into tbl_attach (uuid, uploadpath, filename,
        filetype, bno)
        values (#{uuid}, #{uploadPath}, #{fileName},
        #{fileType}, #{bno} )
    </insert>

    <delete id="delete">
        delete from tbl_attach where uuid = #{uuid}
    </delete>

    <select id="findByBno" resultType="org.zerock.domain.BoardAttachVO">
        select * from tbl_attach where bno = #{bno}
    </select>

    <delete id="deleteAll">
        delete tbl_attach where bno = #{bno}
    </delete>

    <select id="getOldFiles" resultType="org.zerock.domain.BoardAttachVO">
        select * from tbl_attach where uploadpath = to_char(sysdate -1 ,'yyyy\mm\dd')
    </select>
</mapper>
  • register.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
    pageEncoding="UTF-8"%>
<%@ taglib uri="http://java.sun.com/jsp/jstl/core" prefix="c" %>
<%@ taglib uri="http://java.sun.com/jsp/jstl/fmt" prefix="fmt" %>

<%@include file="../includes/header.jsp"%>

<style type="text/css">
    .uploadResult{
        width:100%;
        background-color: gray;
    }

    .uploadResult ul{
        display:flex;
        flex-flow: row;
        justify-content: center;
        align-items: center;
    }

    .uploadResult ul li {
        list-style: none;
        padding: 10px;
    }

    .uploadResult ul li img{
        width: 100px;
    }
</style>

<!-- /.row -->
<div class="row">
    <div class="col-lg-12">
        <h1 class="panel-heading">Board Register</h1>
    </div>
</div>
<!-- /.row -->
<div class="row">
    <div class="col-lg-12">
        <div class="panel panel-default">
            <div class="panel-heading">Board Register</div>
            <!-- /.panel-heading -->
            <div class="panel-body">
                <form role="form" action="/board/register" method="post">
                    <div class="form-group">
                        <label>Title</label><input class="form-control" name="title">
                    </div>
                    <div class="form-group">
                        <label>Text area</label><textarea class="form-control" rows="3" name="content"></textarea>
                    </div>
                    <div class="form-group">
                        <label>Writer</label><input class="form-control" name="writer">
                    </div>
                    <button type="submit" class="btn btn-default">Submit Button</button>
                    <button type="reset" class="btn btn-default">Reset Button</button>
                </form>
            </div>
        </div>
    </div>
</div>

<div class="row">
    <div class="col-lg-12">
        <div class="panel panel-default">

            <div class="panel-heading">File Attach</div>
            <!-- /.panel-heading -->
            <div class="panel-body">
                <div class="form-group uploadDiv">
                    <input type="file" name='uploadFile' multiple>
                </div>

                <div class='uploadResult'>
                    <ul>

                    </ul>
                </div>
            </div>
        </div>
    </div>
</div>

<script>

    $(document).ready(function(e) {

        var formObj = $("form[role='form']");

        $("button[type='submit']").on("click", function(e) {

            e.preventDefault();

            console.log("submit clicked");

            var str = "";

            $(".uploadResult ul li").each(function(i, obj){

                  var jobj = $(obj);

                console.dir(jobj);
                console.log("-------------------------");
                console.log(jobj.data("filename"));


                str += "<input type='hidden' name='attachList["+i+"].fileName' value='"+jobj.data("filename")+"'>";
                str += "<input type='hidden' name='attachList["+i+"].uuid' value='"+jobj.data("uuid")+"'>";
                str += "<input type='hidden' name='attachList["+i+"].uploadPath' value='"+jobj.data("path")+"'>";
                str += "<input type='hidden' name='attachList["+i+"].fileType' value='"+ jobj.data("type")+"'>";

            });

            console.log(str);

            formObj.append(str).submit();

        });

        $(".uploadResult").on("click", "button", function(e){
            console.log("delete file");

            var targetFile = $(this).data("file");
            var type = $(this).data("type");

            var targetLi = $(this).closest("li");

            $.ajax({
              url: '/deleteFile',
              data: {fileName: targetFile, type:type},
              dataType:'text',
              type: 'POST',
                success: function(result){
                   alert(result);

                   targetLi.remove();
                 }
            }); //$.ajax
        });
    });

    var regex = new RegExp("(.*?)\.(exe|sh|zip|alz)$");
    var maxSize = 5242880; //5MB

    function checkExtension(fileName, fileSize) {

        if (fileSize >= maxSize) {
            alert("파일 사이즈 초과");
            return false;
        }

        if (regex.test(fileName)) {
            alert("해당 종류의 파일은 업로드할 수 없습니다.");
            return false;
        }
        return true;
    }

    $("input[type='file']").change(function(e) {

        var formData = new FormData();

        var inputFile = $("input[name='uploadFile']");

        var files = inputFile[0].files;

        for (var i = 0; i < files.length; i++) {

            if (!checkExtension(files[i].name, files[i].size)) {
                return false;
            }
            formData.append("uploadFile", files[i]);

        }

        $.ajax({
            url : '/uploadAjaxAction',
            processData : false,
            contentType : false,
            data : formData,
            type : 'POST',
            dataType : 'json',
            success : function(result) {
                console.log(result);
                showUploadResult(result); //업로드 결과 처리 함수

            }
        }); //$.ajax

    });

    function showUploadResult(uploadResultArr) {
        if (!uploadResultArr || uploadResultArr.length == 0) {
            return;
        }

        var uploadUL = $(".uploadResult ul");

        var str = "";

        $(uploadResultArr).each(function(i, obj) {
            if (obj.image) {
                var fileCallPath = encodeURIComponent(obj.uploadPath + "/s_" + obj.uuid + "_" + obj.fileName);
                str += "<li data-path='"+obj.uploadPath+"'";
                str +=" data-uuid='"+obj.uuid+"' data-filename='"+obj.fileName+"' data-type='"+obj.image+"'"
                str +" ><div>";
                str += "<span> " + obj.fileName + "</span>";
                str += "<button type='button' data-file=\'"+fileCallPath+"\' "
                str += "data-type='image' class='btn btn-warning btn-circle'><i class='fa fa-times'></i></button><br>";
                str += "<img src='/display?fileName=" + fileCallPath + "'>";
                str += "</div>";
                str + "</li>";
            } else {
                var fileCallPath = encodeURIComponent(obj.uploadPath + "/" + obj.uuid + "_" + obj.fileName);
                var fileLink = fileCallPath.replace(new RegExp(/\\/g), "/");
                    str += "<li "
                str += "data-path='"+obj.uploadPath+"' data-uuid='"+obj.uuid+"' data-filename='"+obj.fileName+"' data-type='"+obj.image+"' ><div>";
                str += "<span> " + obj.fileName + "</span>";
                str += "<button type='button' data-file=\'"+fileCallPath+"\' data-type='file' "
                str += "class='btn btn-warning btn-circle'><i class='fa fa-times'></i></button><br>";
                str += "<img src='/resources/img/attach.png'></a>";
                str += "</div>";
                str + "</li>";
            }
        });

        uploadUL.append(str);
    }
</script>

<%@include file="../includes/footer.jsp"%>
  • get.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
  pageEncoding="UTF-8"%>
<%@ taglib uri="http://java.sun.com/jsp/jstl/core" prefix="c"%>
<%@ taglib uri="http://java.sun.com/jsp/jstl/fmt" prefix="fmt"%>
<%@include file="../includes/header.jsp"%>


<div class="row">
  <div class="col-lg-12">
    <h1 class="page-header">Board Read</h1>
  </div>
  <!-- /.col-lg-12 -->
</div>
<!-- /.row -->

<div class="row">
  <div class="col-lg-12">
    <div class="panel panel-default">

      <div class="panel-heading">Board Read Page</div>
      <!-- /.panel-heading -->
      <div class="panel-body">

          <div class="form-group">
          <label>Bno</label> <input class="form-control" name='bno'
            value='<c:out value="${board.bno }"/>' readonly="readonly">
        </div>

        <div class="form-group">
          <label>Title</label> <input class="form-control" name='title'
            value='<c:out value="${board.title }"/>' readonly="readonly">
        </div>

        <div class="form-group">
          <label>Text area</label>
          <textarea class="form-control" rows="3" name='content'
            readonly="readonly"><c:out value="${board.content}" /></textarea>
        </div>

        <div class="form-group">
          <label>Writer</label> <input class="form-control" name='writer'
            value='<c:out value="${board.writer }"/>' readonly="readonly">
        </div>

<%--         <button data-oper='modify' class="btn btn-default">
        <a href="/board/modify?bno=<c:out value="${board.bno}"/>">Modify</a></button>
        <button data-oper='list' class="btn btn-info">
        <a href="/board/list">List</a></button> --%>


<button data-oper='modify' class="btn btn-default">Modify</button>
<button data-oper='list' class="btn btn-info">List</button>

<%-- <form id='operForm' action="/boad/modify" method="get">
  <input type='hidden' id='bno' name='bno' value='<c:out value="${board.bno}"/>'>
</form> --%>


<form id='operForm' action="/boad/modify" method="get">
  <input type='hidden' id='bno' name='bno' value='<c:out value="${board.bno}"/>'>
  <input type='hidden' name='pageNum' value='<c:out value="${cri.pageNum}"/>'>
  <input type='hidden' name='amount' value='<c:out value="${cri.amount}"/>'>
  <input type='hidden' name='keyword' value='<c:out value="${cri.keyword}"/>'>
  <input type='hidden' name='type' value='<c:out value="${cri.type}"/>'>

</form>



      </div>
      <!--  end panel-body -->

    </div>
    <!--  end panel-body -->
  </div>
  <!-- end panel -->
</div>
<!-- /.row -->



<div class='bigPictureWrapper'>
  <div class='bigPicture'>
  </div>
</div>



<style>
.uploadResult {
  width:100%;
  background-color: gray;
}
.uploadResult ul{
  display:flex;
  flex-flow: row;
  justify-content: center;
  align-items: center;
}
.uploadResult ul li {
  list-style: none;
  padding: 10px;
  align-content: center;
  text-align: center;
}
.uploadResult ul li img{
  width: 100px;
}
.uploadResult ul li span {
  color:white;
}
.bigPictureWrapper {
  position: absolute;
  display: none;
  justify-content: center;
  align-items: center;
  top:0%;
  width:100%;
  height:100%;
  background-color: gray;
  z-index: 100;
  background:rgba(255,255,255,0.5);
}
.bigPicture {
  position: relative;
  display:flex;
  justify-content: center;
  align-items: center;
}

.bigPicture img {
  width:600px;
}

</style>



<div class="row">
  <div class="col-lg-12">
    <div class="panel panel-default">

      <div class="panel-heading">Files</div>
      <!-- /.panel-heading -->
      <div class="panel-body">

        <div class='uploadResult'>
          <ul>
          </ul>
        </div>
      </div>
      <!--  end panel-body -->
    </div>
    <!--  end panel-body -->
  </div>
  <!-- end panel -->
</div>
<!-- /.row -->


<div class='row'>

  <div class="col-lg-12">

    <!-- /.panel -->
    <div class="panel panel-default">
<!--       <div class="panel-heading">
        <i class="fa fa-comments fa-fw"></i> Reply
      </div> -->

      <div class="panel-heading">
        <i class="fa fa-comments fa-fw"></i> Reply
        <button id='addReplyBtn' class='btn btn-primary btn-xs pull-right'>New Reply</button>
      </div>


      <!-- /.panel-heading -->
      <div class="panel-body">

        <ul class="chat">

        </ul>
        <!-- ./ end ul -->
      </div>
      <!-- /.panel .chat-panel -->

    <div class="panel-footer"></div>


        </div>
  </div>
  <!-- ./ end row -->
</div>



<!-- Modal -->
      <div class="modal fade" id="myModal" tabindex="-1" role="dialog"
        aria-labelledby="myModalLabel" aria-hidden="true">
        <div class="modal-dialog">
          <div class="modal-content">
            <div class="modal-header">
              <button type="button" class="close" data-dismiss="modal"
                aria-hidden="true">&times;</button>
              <h4 class="modal-title" id="myModalLabel">REPLY MODAL</h4>
            </div>
            <div class="modal-body">
              <div class="form-group">
                <label>Reply</label>
                <input class="form-control" name='reply' value='New Reply!!!!'>
              </div>
              <div class="form-group">
                <label>Replyer</label>
                <input class="form-control" name='replyer' value='replyer'>
              </div>
              <div class="form-group">
                <label>Reply Date</label>
                <input class="form-control" name='replyDate' value='2018-01-01 13:13'>
              </div>

            </div>
<div class="modal-footer">
        <button id='modalModBtn' type="button" class="btn btn-warning">Modify</button>
        <button id='modalRemoveBtn' type="button" class="btn btn-danger">Remove</button>
        <button id='modalRegisterBtn' type="button" class="btn btn-primary">Register</button>
        <button id='modalCloseBtn' type="button" class="btn btn-default">Close</button>
      </div>          </div>
          <!-- /.modal-content -->
        </div>
        <!-- /.modal-dialog -->
      </div>
      <!-- /.modal -->



<script type="text/javascript" src="/resources/js/reply.js"></script>

<script>

$(document).ready(function () {

  var bnoValue = '<c:out value="${board.bno}"/>';
  var replyUL = $(".chat");

    showList(1);

    function showList(page){

        console.log("show list " + page);

        replyService.getList({bno:bnoValue,page: page|| 1 }, function(replyCnt, list) {

        console.log("replyCnt: "+ replyCnt );
        console.log("list: " + list);
        console.log(list);

        if(page == -1){
          pageNum = Math.ceil(replyCnt/10.0);
          showList(pageNum);
          return;
        }

         var str="";

         if(list == null || list.length == 0){
           return;
         }

         for (var i = 0, len = list.length || 0; i < len; i++) {
           str +="<li class='left clearfix' data-rno='"+list[i].rno+"'>";
           str +="  <div><div class='header'><strong class='primary-font'>["
               +list[i].rno+"] "+list[i].replyer+"</strong>";
           str +="    <small class='pull-right text-muted'>"
               +replyService.displayTime(list[i].replyDate)+"</small></div>";
           str +="    <p>"+list[i].reply+"</p></div></li>";
         }

         replyUL.html(str);

         showReplyPage(replyCnt);


       });//end function

     }//end showList

    var pageNum = 1;
    var replyPageFooter = $(".panel-footer");

    function showReplyPage(replyCnt){

      var endNum = Math.ceil(pageNum / 10.0) * 10;
      var startNum = endNum - 9;

      var prev = startNum != 1;
      var next = false;

      if(endNum * 10 >= replyCnt){
        endNum = Math.ceil(replyCnt/10.0);
      }

      if(endNum * 10 < replyCnt){
        next = true;
      }

      var str = "<ul class='pagination pull-right'>";

      if(prev){
        str+= "<li class='page-item'><a class='page-link' href='"+(startNum -1)+"'>Previous</a></li>";
      }



      for(var i = startNum ; i <= endNum; i++){

        var active = pageNum == i? "active":"";

        str+= "<li class='page-item "+active+" '><a class='page-link' href='"+i+"'>"+i+"</a></li>";
      }

      if(next){
        str+= "<li class='page-item'><a class='page-link' href='"+(endNum + 1)+"'>Next</a></li>";
      }

      str += "</ul></div>";

      console.log(str);

      replyPageFooter.html(str);
    }

    replyPageFooter.on("click","li a", function(e){
        e.preventDefault();
        console.log("page click");

        var targetPageNum = $(this).attr("href");

        console.log("targetPageNum: " + targetPageNum);

        pageNum = targetPageNum;

        showList(pageNum);
      });


/*     function showList(page){

      replyService.getList({bno:bnoValue,page: page|| 1 }, function(list) {

        var str="";
       if(list == null || list.length == 0){

        replyUL.html("");

        return;
      }
       for (var i = 0, len = list.length || 0; i < len; i++) {
           str +="<li class='left clearfix' data-rno='"+list[i].rno+"'>";
           str +="  <div><div class='header'><strong class='primary-font'>"+list[i].replyer+"</strong>";
           str +="    <small class='pull-right text-muted'>"+replyService.displayTime(list[i].replyDate)+"</small></div>";
           str +="    <p>"+list[i].reply+"</p></div></li>";
         }


    replyUL.html(str);

      });//end function

   }//end showList */

    var modal = $(".modal");
    var modalInputReply = modal.find("input[name='reply']");
    var modalInputReplyer = modal.find("input[name='replyer']");
    var modalInputReplyDate = modal.find("input[name='replyDate']");

    var modalModBtn = $("#modalModBtn");
    var modalRemoveBtn = $("#modalRemoveBtn");
    var modalRegisterBtn = $("#modalRegisterBtn");

    $("#modalCloseBtn").on("click", function(e){

        modal.modal('hide');
    });

    $("#addReplyBtn").on("click", function(e){

      modal.find("input").val("");
      modalInputReplyDate.closest("div").hide();
      modal.find("button[id !='modalCloseBtn']").hide();

      modalRegisterBtn.show();

      $(".modal").modal("show");

    });


    modalRegisterBtn.on("click",function(e){

      var reply = {
            reply: modalInputReply.val(),
            replyer:modalInputReplyer.val(),
            bno:bnoValue
          };
      replyService.add(reply, function(result){

        alert(result);

        modal.find("input").val("");
        modal.modal("hide");

        //showList(1);
        showList(-1);

      });

    });


  //댓글 조회 클릭 이벤트 처리
    $(".chat").on("click", "li", function(e){

      var rno = $(this).data("rno");

      replyService.get(rno, function(reply){

        modalInputReply.val(reply.reply);
        modalInputReplyer.val(reply.replyer);
        modalInputReplyDate.val(replyService.displayTime( reply.replyDate))
        .attr("readonly","readonly");
        modal.data("rno", reply.rno);

        modal.find("button[id !='modalCloseBtn']").hide();
        modalModBtn.show();
        modalRemoveBtn.show();

        $(".modal").modal("show");

      });
    });


/*     modalModBtn.on("click", function(e){

      var reply = {rno:modal.data("rno"), reply: modalInputReply.val()};

      replyService.update(reply, function(result){

        alert(result);
        modal.modal("hide");
        showList(1);

      });

    });

    modalRemoveBtn.on("click", function (e){

        var rno = modal.data("rno");

        replyService.remove(rno, function(result){

            alert(result);
            modal.modal("hide");
            showList(1);

        });

      }); */

    modalModBtn.on("click", function(e){

         var reply = {rno:modal.data("rno"), reply: modalInputReply.val()};

         replyService.update(reply, function(result){

           alert(result);
           modal.modal("hide");
           showList(pageNum);

         });

       });


       modalRemoveBtn.on("click", function (e){

         var rno = modal.data("rno");

         replyService.remove(rno, function(result){

             alert(result);
             modal.modal("hide");
             showList(pageNum);

         });

       });


});

</script>



<script>

/* console.log("===============");
console.log("JS TEST");

var bnoValue = '<c:out value="${board.bno}"/>'; */

//for replyService add test
/* replyService.add(

    {reply:"JS Test", replyer:"tester", bno:bnoValue}
    ,
    function(result){
      alert("RESULT: " + result);
    }
); */


//reply List Test
/* replyService.getList({bno:bnoValue, page:1}, function(list){

      for(var i = 0,  len = list.length||0; i < len; i++ ){
        console.log(list[i]);
      }
});
 */


/*  //17번 댓글 삭제 테스트
 replyService.remove(17, function(count) {

   console.log(count);

   if (count === "success") {
     alert("REMOVED");
   }
 }, function(err) {
   alert('ERROR...');
 });
 */


//12번 댓글 수정
/* replyService.update({
  rno : 12,
  bno : bnoValue,
  reply : "Modified Reply...."
}, function(result) {

  alert("수정 완료...");

});
 */

</script>


<script type="text/javascript">
$(document).ready(function() {

  var operForm = $("#operForm");

  $("button[data-oper='modify']").on("click", function(e){

    operForm.attr("action","/board/modify").submit();

  });


  $("button[data-oper='list']").on("click", function(e){

    operForm.find("#bno").remove();
    operForm.attr("action","/board/list")
    operForm.submit();

  });
});
</script>


<script>


$(document).ready(function(){

  (function(){

    var bno = '<c:out value="${board.bno}"/>';

    /* $.getJSON("/board/getAttachList", {bno: bno}, function(arr){

      console.log(arr);


    }); *///end getjson
    $.getJSON("/board/getAttachList", {bno: bno}, function(arr){

       console.log(arr);

       var str = "";

       $(arr).each(function(i, attach){

         //image type
         if(attach.fileType){
           var fileCallPath =  encodeURIComponent( attach.uploadPath+ "/s_"+attach.uuid +"_"+attach.fileName);

           str += "<li data-path='"+attach.uploadPath+"' data-uuid='"+attach.uuid+"' data-filename='"+attach.fileName+"' data-type='"+attach.fileType+"' ><div>";
           str += "<img src='/display?fileName="+fileCallPath+"'>";
           str += "</div>";
           str +"</li>";
         }else{

           str += "<li data-path='"+attach.uploadPath+"' data-uuid='"+attach.uuid+"' data-filename='"+attach.fileName+"' data-type='"+attach.fileType+"' ><div>";
           str += "<span> "+ attach.fileName+"</span><br/>";
           str += "<img src='/resources/img/attach.png'></a>";
           str += "</div>";
           str +"</li>";
         }
       });

       $(".uploadResult ul").html(str);


     });//end getjson


  })();//end function

  $(".uploadResult").on("click","li", function(e){

    console.log("view image");

    var liObj = $(this);

    var path = encodeURIComponent(liObj.data("path")+"/" + liObj.data("uuid")+"_" + liObj.data("filename"));

    if(liObj.data("type")){
      showImage(path.replace(new RegExp(/\\/g),"/"));
    }else {
      //download
      self.location ="/download?fileName="+path
    }


  });

  function showImage(fileCallPath){

    alert(fileCallPath);

    $(".bigPictureWrapper").css("display","flex").show();

    $(".bigPicture")
    .html("<img src='/display?fileName="+fileCallPath+"' >")
    .animate({width:'100%', height: '100%'}, 1000);

  }

  $(".bigPictureWrapper").on("click", function(e){
    $(".bigPicture").animate({width:'0%', height: '0%'}, 1000);
    setTimeout(function(){
      $('.bigPictureWrapper').hide();
    }, 1000);
  });


});

</script>



<%@include file="../includes/footer.jsp"%>
  • modify.jsp
<%@ page language="java" contentType="text/html; charset=UTF-8"
  pageEncoding="UTF-8"%>
<%@ taglib uri="http://java.sun.com/jsp/jstl/core" prefix="c"%>
<%@ taglib uri="http://java.sun.com/jsp/jstl/fmt" prefix="fmt"%>
<%@include file="../includes/header.jsp"%>


<div class="row">
  <div class="col-lg-12">
    <h1 class="page-header">Board Modify</h1>
  </div>
  <!-- /.col-lg-12 -->
</div>
<!-- /.row -->

<div class="row">
  <div class="col-lg-12">
    <div class="panel panel-default">

      <div class="panel-heading">Board Modify</div>
      <!-- /.panel-heading -->
      <div class="panel-body">

      <form role="form" action="/board/modify" method="post">

        <input type='hidden' name='pageNum' value='<c:out value="${cri.pageNum }"/>'>
        <input type='hidden' name='amount' value='<c:out value="${cri.amount }"/>'>
        <input type='hidden' name='type' value='<c:out value="${cri.type }"/>'>
        <input type='hidden' name='keyword' value='<c:out value="${cri.keyword }"/>'>


<div class="form-group">
  <label>Bno</label>
  <input class="form-control" name='bno'
     value='<c:out value="${board.bno }"/>' readonly="readonly">
</div>

<div class="form-group">
  <label>Title</label>
  <input class="form-control" name='title'
    value='<c:out value="${board.title }"/>' >
</div>

<div class="form-group">
  <label>Text area</label>
  <textarea class="form-control" rows="3" name='content' ><c:out value="${board.content}"/></textarea>
</div>

<div class="form-group">
  <label>Writer</label>
  <input class="form-control" name='writer'
    value='<c:out value="${board.writer}"/>' readonly="readonly">
</div>

<div class="form-group">
  <label>RegDate</label>
  <input class="form-control" name='regDate'
    value='<fmt:formatDate pattern = "yyyy/MM/dd" value = "${board.regdate}" />'  readonly="readonly">
</div>

<div class="form-group">
  <label>Update Date</label>
  <input class="form-control" name='updateDate'
    value='<fmt:formatDate pattern = "yyyy/MM/dd" value = "${board.updateDate}" />'  readonly="readonly">
</div>



  <button type="submit" data-oper='modify' class="btn btn-default">Modify</button>
  <button type="submit" data-oper='remove' class="btn btn-danger">Remove</button>
  <button type="submit" data-oper='list' class="btn btn-info">List</button>
</form>


      </div>
      <!--  end panel-body -->

    </div>
    <!--  end panel-body -->
  </div>
  <!-- end panel -->
</div>
<!-- /.row -->

<div class='bigPictureWrapper'>
  <div class='bigPicture'>
  </div>
</div>



<style>
.uploadResult {
  width:100%;
  background-color: gray;
}
.uploadResult ul{
  display:flex;
  flex-flow: row;
  justify-content: center;
  align-items: center;
}
.uploadResult ul li {
  list-style: none;
  padding: 10px;
  align-content: center;
  text-align: center;
}
.uploadResult ul li img{
  width: 100px;
}
.uploadResult ul li span {
  color:white;
}
.bigPictureWrapper {
  position: absolute;
  display: none;
  justify-content: center;
  align-items: center;
  top:0%;
  width:100%;
  height:100%;
  background-color: gray;
  z-index: 100;
  background:rgba(255,255,255,0.5);
}
.bigPicture {
  position: relative;
  display:flex;
  justify-content: center;
  align-items: center;
}

.bigPicture img {
  width:600px;
}

</style>



<div class="row">
  <div class="col-lg-12">
    <div class="panel panel-default">

      <div class="panel-heading">Files</div>
      <!-- /.panel-heading -->
      <div class="panel-body">
        <div class="form-group uploadDiv">
            <input type="file" name='uploadFile' multiple="multiple">
        </div>

        <div class='uploadResult'>
          <ul>

          </ul>
        </div>
      </div>
      <!--  end panel-body -->

    </div>
    <!--  end panel-body -->
  </div>
  <!-- end panel -->
</div>
<!-- /.row -->

<script type="text/javascript">
$(document).ready(function() {


      var formObj = $("form");

      $('button').on("click", function(e){

        e.preventDefault();

        var operation = $(this).data("oper");

        console.log(operation);

        if(operation === 'remove'){
          formObj.attr("action", "/board/remove");

        }else if(operation === 'list'){
          //move to list
          formObj.attr("action", "/board/list").attr("method","get");

          var pageNumTag = $("input[name='pageNum']").clone();
          var amountTag = $("input[name='amount']").clone();
          var keywordTag = $("input[name='keyword']").clone();
          var typeTag = $("input[name='type']").clone();

          formObj.empty();

          formObj.append(pageNumTag);
          formObj.append(amountTag);
          formObj.append(keywordTag);
          formObj.append(typeTag);

        }else if(operation === 'modify'){

            console.log("submit clicked");

            var str = "";

            $(".uploadResult ul li").each(function(i, obj){

              var jobj = $(obj);

              console.dir(jobj);

              str += "<input type='hidden' name='attachList["+i+"].fileName' value='"+jobj.data("filename")+"'>";
              str += "<input type='hidden' name='attachList["+i+"].uuid' value='"+jobj.data("uuid")+"'>";
              str += "<input type='hidden' name='attachList["+i+"].uploadPath' value='"+jobj.data("path")+"'>";
              str += "<input type='hidden' name='attachList["+i+"].fileType' value='"+ jobj.data("type")+"'>";

            });
            formObj.append(str).submit();
        }

        formObj.submit();
      });

});
</script>


<script>

$(document).ready(function() {
  (function(){

    var bno = '<c:out value="${board.bno}"/>';

    $.getJSON("/board/getAttachList", {bno: bno}, function(arr){

      console.log(arr);

      var str = "";


      $(arr).each(function(i, attach){

          //image type
          if(attach.fileType){
            var fileCallPath =  encodeURIComponent( attach.uploadPath+ "/s_"+attach.uuid +"_"+attach.fileName);

            str += "<li data-path='"+attach.uploadPath+"' data-uuid='"+attach.uuid+"' "
            str +=" data-filename='"+attach.fileName+"' data-type='"+attach.fileType+"' ><div>";
            str += "<span> "+ attach.fileName+"</span>";
            str += "<button type='button' data-file=\'"+fileCallPath+"\' data-type='image' "
            str += "class='btn btn-warning btn-circle'><i class='fa fa-times'></i></button><br>";
            str += "<img src='/display?fileName="+fileCallPath+"'>";
            str += "</div>";
            str +"</li>";
          }else{

            str += "<li data-path='"+attach.uploadPath+"' data-uuid='"+attach.uuid+"' "
            str += "data-filename='"+attach.fileName+"' data-type='"+attach.fileType+"' ><div>";
            str += "<span> "+ attach.fileName+"</span><br/>";
            str += "<button type='button' data-file=\'"+fileCallPath+"\' data-type='file' "
            str += " class='btn btn-warning btn-circle'><i class='fa fa-times'></i></button><br>";
            str += "<img src='/resources/img/attach.png'></a>";
            str += "</div>";
            str +"</li>";
          }
       });


      $(".uploadResult ul").html(str);

    });//end getjson
  })();//end function


  $(".uploadResult").on("click", "button", function(e){

    console.log("delete file");

    if(confirm("Remove this file? ")){

      var targetLi = $(this).closest("li");
      targetLi.remove();
    }
  });

  var regex = new RegExp("(.*?)\.(exe|sh|zip|alz)$");
  var maxSize = 5242880; //5MB

  function checkExtension(fileName, fileSize){

    if(fileSize >= maxSize){
      alert("파일 사이즈 초과");
      return false;
    }

    if(regex.test(fileName)){
      alert("해당 종류의 파일은 업로드할 수 없습니다.");
      return false;
    }
    return true;
  }

  $("input[type='file']").change(function(e){

    var formData = new FormData();

    var inputFile = $("input[name='uploadFile']");

    var files = inputFile[0].files;

    for(var i = 0; i < files.length; i++){

      if(!checkExtension(files[i].name, files[i].size) ){
        return false;
      }
      formData.append("uploadFile", files[i]);

    }

    $.ajax({
      url: '/uploadAjaxAction',
      processData: false,
      contentType: false,data:
      formData,type: 'POST',
      dataType:'json',
        success: function(result){
          console.log(result);
          showUploadResult(result); //업로드 결과 처리 함수

      }
    }); //$.ajax

  });

  function showUploadResult(uploadResultArr){

    if(!uploadResultArr || uploadResultArr.length == 0){ return; }

    var uploadUL = $(".uploadResult ul");

    var str ="";

    $(uploadResultArr).each(function(i, obj){

        if(obj.image){
            var fileCallPath =  encodeURIComponent( obj.uploadPath+ "/s_"+obj.uuid +"_"+obj.fileName);
            str += "<li data-path='"+obj.uploadPath+"'";
            str +=" data-uuid='"+obj.uuid+"' data-filename='"+obj.fileName+"' data-type='"+obj.image+"'"
            str +" ><div>";
            str += "<span> "+ obj.fileName+"</span>";
            str += "<button type='button' data-file=\'"+fileCallPath+"\' "
            str += "data-type='image' class='btn btn-warning btn-circle'><i class='fa fa-times'></i></button><br>";
            str += "<img src='/display?fileName="+fileCallPath+"'>";
            str += "</div>";
            str +"</li>";
        }else{
            var fileCallPath =  encodeURIComponent( obj.uploadPath+"/"+ obj.uuid +"_"+obj.fileName);
            var fileLink = fileCallPath.replace(new RegExp(/\\/g),"/");

            str += "<li "
            str += "data-path='"+obj.uploadPath+"' data-uuid='"+obj.uuid+"' data-filename='"+obj.fileName+"' data-type='"+obj.image+"' ><div>";
            str += "<span> "+ obj.fileName+"</span>";
            str += "<button type='button' data-file=\'"+fileCallPath+"\' data-type='file' "
            str += "class='btn btn-warning btn-circle'><i class='fa fa-times'></i></button><br>";
            str += "<img src='/resources/img/attach.png'></a>";
            str += "</div>";
            str +"</li>";
        }

    });

    uploadUL.append(str);
  }

});

</script>

<%@include file="../includes/footer.jsp"%>
  • BoardServiceImpl.java
package org.zerock.service;

import java.util.List;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;
import org.springframework.transaction.annotation.Transactional;
import org.zerock.domain.BoardAttachVO;
import org.zerock.domain.BoardVO;
import org.zerock.domain.Criteria;
import org.zerock.mapper.BoardAttachMapper;
import org.zerock.mapper.BoardMapper;

import lombok.AllArgsConstructor;
import lombok.Setter;
import lombok.extern.log4j.Log4j;

@Log4j
@Service
@AllArgsConstructor
public class BoardServiceImpl implements BoardService{
//    @Setter(onMethod_ = @Autowired)
//    private BoardMapper mapper;

    // Spring 4.3 이상에서 자동 처리
    private BoardMapper mapper;

    private BoardAttachMapper attachMapper;

    @Override
    public void register(BoardVO board) {
        log.info("register....." + board);

        mapper.insertSelectKey(board);

        if(board.getAttachList() == null || board.getAttachList().size() <= 0 ) {
            return;
        }

        board.getAttachList().forEach(attach -> {
            attach.setBno(board.getBno());
            attachMapper.insert(attach);
        });
    }

    @Override
    public BoardVO get(Long bno) {
        log.info("get.........." + bno);

        return mapper.read(bno);
    }

    @Transactional
    @Override
    public boolean modify(BoardVO board) {
        log.info("modify....." + board);

        attachMapper.deleteAll(board.getBno());

        boolean modifyResult = mapper.update(board) == 1;

        if(modifyResult && board.getAttachList() != null && board.getAttachList().size() > 0) {
            board.getAttachList().forEach(attach -> {
                attach.setBno(board.getBno());
                attachMapper.insert(attach);
            });
        }

        return modifyResult;
    }

    @Transactional
    @Override
    public boolean remove(Long bno) {
        log.info("remove........" + bno);

        attachMapper.deleteAll(bno);

        return mapper.delete(bno) == 1;
    }

//    @Override
//    public List<BoardVO> getList() {
//        log.info("getList.........");
//
//        return mapper.getList();
//    }

    @Override
    public List<BoardVO> getList(Criteria cri) {
        log.info("get List with criteria : " + cri);

        return mapper.getListWithPaging(cri);
    }

    @Override
    public int getTotal(Criteria cri) {
        return mapper.getTotalCount(cri);
    }

    @Override
    public List<BoardAttachVO> getAttachList(Long bno){
        log.info("get Attach list by bno : " + bno);

        return attachMapper.findByBno(bno);
    }
}
  • BoardService.java
package org.zerock.service;

import java.util.List;

import org.zerock.domain.BoardAttachVO;
import org.zerock.domain.BoardVO;
import org.zerock.domain.Criteria;

public interface BoardService {

    public void register(BoardVO board);

    public BoardVO get(Long bno);

    public boolean modify(BoardVO board);

    public boolean remove(Long bno);

    //public List<BoardVO> getList();

    public List<BoardVO> getList(Criteria cri);

    public int getTotal(Criteria cri);

    public List<BoardAttachVO> getAttachList(Long bno);

}
  • BoardController.java
package org.zerock.controller;

import java.nio.file.Files;
import java.nio.file.Path;
import java.nio.file.Paths;
import java.util.List;

import org.springframework.http.HttpStatus;
import org.springframework.http.MediaType;
import org.springframework.http.ResponseEntity;
import org.springframework.stereotype.Controller;
import org.springframework.ui.Model;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.ModelAttribute;
import org.springframework.web.bind.annotation.PostMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RequestParam;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.servlet.mvc.support.RedirectAttributes;
import org.zerock.domain.BoardAttachVO;
import org.zerock.domain.BoardVO;
import org.zerock.domain.Criteria;
import org.zerock.domain.PageDTO;
import org.zerock.service.BoardService;

import lombok.AllArgsConstructor;
import lombok.extern.log4j.Log4j;

@Controller
@Log4j
@RequestMapping("/board/*")
@AllArgsConstructor
public class BoardController {

    private BoardService service;

    @GetMapping("/list")
    public void list(Criteria cri ,Model model) {
        log.info("list");

        model.addAttribute("list", service.getList(cri));
        model.addAttribute("pageMaker", new PageDTO(cri, service.getTotal(cri)));
    }

    @GetMapping("/register")
    public void register() {

    }

    @PostMapping("/register")
    public String register(BoardVO board, RedirectAttributes rttr) {
        log.info("===================");
        log.info("register: " + board);

        if(board.getAttachList() != null) {
            board.getAttachList().forEach(attach -> log.info(attach));
        }

        log.info("===================");

        service.register(board);

        rttr.addFlashAttribute("result", board.getBno());

        return "redirect:/board/list";
    }

    @GetMapping({"/get", "/modify"})
    public void get(@RequestParam("bno") Long bno, @ModelAttribute("cri") Criteria cri, Model model) {
        log.info("/get or /modify");

        model.addAttribute("board", service.get(bno));
    }

    @PostMapping("/modify")
    public String modify(BoardVO board, @ModelAttribute("cri") Criteria cri, RedirectAttributes rttr) {
        log.info("modify: " + board);

        if(service.modify(board)) {
            rttr.addFlashAttribute("result", "success");
        }

//        rttr.addFlashAttribute("pageNum", cri.getPageNum());
//        rttr.addFlashAttribute("amount", cri.getAmount());
//        rttr.addFlashAttribute("type", cri.getType());
//        rttr.addFlashAttribute("keyword", cri.getKeyword());

        return "redirect:/board/list" + cri.getListLink();
    }

    @PostMapping("/remove")
    public String remove(@RequestParam("bno") Long bno, @ModelAttribute("cri") Criteria cri, RedirectAttributes rttr) {
        log.info("remove....." + bno);

        List<BoardAttachVO> attachList = service.getAttachList(bno);

        if(service.remove(bno)) {
            deleteFiles(attachList);
            rttr.addFlashAttribute("result", "success");
        }

//        rttr.addFlashAttribute("pageNum", cri.getPageNum());
//        rttr.addFlashAttribute("amount", cri.getAmount());
//        rttr.addFlashAttribute("type", cri.getType());
//        rttr.addFlashAttribute("keyword", cri.getKeyword());

        return "redirect:/board/list" + cri.getListLink();
    }

    @GetMapping(value = "/getAttachList", produces = MediaType.APPLICATION_JSON_UTF8_VALUE)
    @ResponseBody
    public ResponseEntity<List<BoardAttachVO>> getAttachList(Long bno) {

        log.info("getAttachList " + bno);

        return new ResponseEntity<>(service.getAttachList(bno), HttpStatus.OK);

    }

    private void deleteFiles(List<BoardAttachVO> attachList) {

        if(attachList == null || attachList.size() == 0) {
          return;
        }

        log.info("delete attach files...................");
        log.info(attachList);

        attachList.forEach(attach -> {
          try {
            Path file  = Paths.get("/Users/tongbook/Desktop/study/upload/"+attach.getUploadPath()+"/" + attach.getUuid()+"_"+ attach.getFileName());

            Files.deleteIfExists(file);

            if(Files.probeContentType(file).startsWith("image")) {

              Path thumbNail = Paths.get("/Users/tongbook/Desktop/study/upload/"+attach.getUploadPath()+"/s_" + attach.getUuid()+"_"+ attach.getFileName());

              Files.delete(thumbNail);
            }

          }catch(Exception e) {
            log.error("delete file error" + e.getMessage());
          }//end catch
        });//end foreachd
      }
}

ch29. 잘못 업로드된 파일 삭제

  • Ajax를 사용하여 첨부파일을 미리 업로드시켰을 때의 문제점

    • 첨부파일만 등록하고 게시물을 등록하지 않았을 때의 문제
    • 게시물을 수정할 때 파일을 삭제했지만 실제로 폴더에서 기존 파일은 삭제되지 않는 문제

  • Quartz 라이브러리 설정

    • pom.xml

      <!-- https://mvnrepository.com/artifact/org.quartz-scheduler/quartz -->
<dependency>
  <groupId>org.quartz-scheduler</groupId>
  <artifactId>quartz</artifactId>
  <version>2.3.0</version>
</dependency>

<dependency>
  <groupId>org.quartz-scheduler</groupId>
  <artifactId>quartz-jobs</artifactId>
  <version>2.3.0</version>
</dependency>

    • root-context.xml (xml 설정)

      • task 체크

        1
      <context:component-scan base-package="org.zerock.task"></context:component-scan>
<task:annotation-driven />

    • RootConfig.java (java 설정)

      @ComponentScan(basePackages="org.zerock.task")

@EnableScheduling

    • FileCheckTask.java

      package org.zerock.task;

import org.springframework.scheduling.annotation.Scheduled;
import org.springframework.stereotype.Component;

import lombok.extern.log4j.Log4j;

@Log4j
@Component
public class FileCheckTask {
  @Scheduled(cron="0 * * * * *")
  public void checkFiles() throws Exception{
      log.warn("File Check Task run.............");

      log.warn("========================================");
  }
}

    • BoardAttachMapper.java

      public List<BoardAttachVO> getOldFiles();

    • BoardAttachMapper.xml

      <select id="getOldFiles" resultType="org.zerock.domain.BoardAttachVO">
  select * from tbl_attach where uploadpath = to_char(sysdate -1 ,'yyyy\mm\dd')
</select>

    • FileCheckTask.java

      package org.zerock.task;

import java.io.File;
import java.nio.file.Path;
import java.nio.file.Paths;
import java.text.SimpleDateFormat;
import java.util.Calendar;
import java.util.Date;
import java.util.List;
import java.util.stream.Collectors;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.scheduling.annotation.Scheduled;
import org.springframework.stereotype.Component;
import org.zerock.domain.BoardAttachVO;
import org.zerock.mapper.BoardAttachMapper;

import lombok.Setter;
import lombok.extern.log4j.Log4j;

@Log4j
@Component
public class FileCheckTask {

  @Setter(onMethod_ = { @Autowired })
  private BoardAttachMapper attachMapper;

  private String getFolderYesterDay() {

      SimpleDateFormat sdf = new SimpleDateFormat("yyyy-MM-dd");

      Calendar cal = Calendar.getInstance();

      cal.add(Calendar.DATE, -1);

      String str = sdf.format(cal.getTime());

      return str.replace("-", File.separator);
  }

  @Scheduled(cron = "0 0 3 * * *")
  public void checkFiles() throws Exception {

      log.warn("File Check Task run.................");
      log.warn(new Date());
      // file list in database
      List<BoardAttachVO> fileList = attachMapper.getOldFiles();

      // ready for check file in directory with database file list
      List<Path> fileListPaths = fileList.stream()
              .map(vo -> Paths.get("C:\\upload", vo.getUploadPath(), vo.getUuid() + "_" + vo.getFileName()))
              .collect(Collectors.toList());

      // image file has thumnail file
      fileList.stream().filter(vo -> vo.isFileType() == true)
              .map(vo -> Paths.get("C:\\upload", vo.getUploadPath(), "s_" + vo.getUuid() + "_" + vo.getFileName()))
              .forEach(p -> fileListPaths.add(p));

      log.warn("===========================================");

      fileListPaths.forEach(p -> log.warn(p));

      // files in yesterday directory
      File targetDir = Paths.get("C:\\upload", getFolderYesterDay()).toFile();

      File[] removeFiles = targetDir.listFiles(file -> fileListPaths.contains(file.toPath()) == false);

      log.warn("-----------------------------------------");
      for (File file : removeFiles) {

          log.warn(file.getAbsolutePath());

          file.delete();

      }
  }
}
728x90
저작자표시 비영리 변경금지 (새창열림)

'개발 서적 > 코드로 배우는 스프링 웹 프로젝트' 카테고리의 다른 글

7장. Spring Web Security를 이용한 로그인 처리  (0) 2022.01.22
5장. AOP와 트랜잭션  (0) 2022.01.22
4장. REST 방식과 Ajax를 이용하는 댓글 처리  (0) 2022.01.22
3장. 기본적인 웹 게시물 관리물 관리  (3) 2022.01.22
2장. 스프링 MVC 설정  (0) 2022.01.22
복사했습니다!

티스토리툴바
